Control Panels

Feature

• Ensure minimum operational down time.
• High Degree of operating personnel safety & dependability.
• Power as well as control contacts are self aligning type.
• There are four distinct- Service, test, isolate & fully withdrawn position.
• In all positions the withdrawal module has got locking facilities.
• Gravity operated shutters are provided to cover live bus bars when modules are removed.
• Draw-out power contacts are type tested at CPRI for 50, KA for 1 Sec with back-up protections.
• Tested to establish continuous current carrying capacity.
• Voltage drop between male & female contacts tested at CPRI.
• Di-electric properties are checked for any leakage through support on which they are mounted.
• Drawout contacts are tested for mechanical endurance test to prove its life. These are available from 32 Amp to 630 Amp.
